Performance Base 65 Quickstart Guide

HIGROUND PERFORMANCE BASE 65 KEYBOARD





>Firmware Update Download< **FIRMWARE COMPATIBLE WITH PERFORMANCE BASE 65 KEYBOARD ONLY



 In-box Contents:

  • 1x PERFORMANCE BASE 65 KEYBOARD
  • 1x USB-C CABLE
  • 1x KEYCAP PULLER
  • 1x SWITCH PULLER



 Keyboard modes & shortcuts:

FN + ESC
(Hold 5s)
Reset keyboard and restore to factory settings
FN + Win key
Enable or disable the Windows key, Game mode
FN + O Insert key
FN + P Print Screen key
FN + PgUp Home key
FN + PdDn End key
FN + (1~+) F1~F12 key
FN + Left Ctrl
(Hold 2s)
Enable or disable the F1-F12 function key lock
Activate = Keyboard flash white LED x2
Deactivate = Keyboard flash white LED x1
FN + UP Arrow
Decrease lighting brightness
(0-7 levels)
FN + Down Arrow
Increase lighting brightness
(0-7 levels)
FN + Left Arrow
Decrease lighting speed
(1-7 levels)
FN + Right Arrow
Increase lighting speed
(1-7 levels)



 Magnet Switch Sensitivity Adjustment:

FN + Enter
Enter Sensitivity Adjustment Mode
Sensitivity Adjustment
'~' key to select all keys or
Press any key to select custom keys

Del = Restore default value
PgUp = Sensitivity Increase
PgDn = Sensitivity Decrease

FN = Exit Sensitivity Adjustment Mode
FN + Space (hold 3s)
Toggles through 3 preset profiles below
Profile 1
Keyboard flash PURPLE LED x2
Preset Rapid Trigger = Medium (Step 9 - 1.6mm)
Profile 2
Keyboard flash YELLOW LED x2
Preset Rapid Trigger = Slow (Step 21 - 4.0mm)
Profile 3
Keyboard flash GREEN LED x2
Preset Rapid Trigger = Fast (Step 3 - 0.4mm)
Note: Sensitivity adjustments made to each of the profiles will be saved. To restore a specific profile to default, Enter sensitivity adjustment mode, (~) select all keys and then (Del) restore.



 Magnet Switch Sensitivity Steps:

Steps Sensitivity
1 0.1mm
2 0.2mm
3 0.4mm
4 0.6mm
5 0.8mm
6 1mm
7 1.2mm
8 1.4mm
9 1.6mm
10 1.8mm
11 2mm
12 2.2mm
13 2.4mm
14 2.6mm
15 2.8mm
16 3mm
17 3.2mm
18 3.4mm
19 3.6mm
20 3.8mm
21 4mm



 Lighting Effects:

FN + Tab
Rotate lighting effects
16 onboard effects:
FN + C
Cycle colors to White, Red, Green, Blue, Yellow, Purple, Cyan
Rightwave Lighting effect #1
Breathe Lighting effect #2
Radiance Lighting effect #3
Hitaoe Lighting effect #4
Radar Lighting effect #5
Crossline Lighting effect #6
Zen Lighting effect #7
Laser Lighting effect #8
Crosswave Lighting effect #9
Spectrum Lighting effect #10
Explosion Lighting effect #11
Silvasurfa Lighting effect #12
Higround Lighting effect #13
Tripple Lighting effect #14
BreatheRGB Lighting effect #15
Solid Lighting effect #16





Multimedia Functions:

FN + ,< Previous Track
FN + M Play/Pause
FN + .> Skip Track
FN + L Sound Volume Up
FN + K
Sound Volume Down
FN + J Sound Mute
